وصف
APCF-63-85017 قلب سخان التدفئة والتهوية وتكييف الهواء (ميكانيكية) - يناسب رينو 4 & 5 - المرجع المتقاطع: نيسن 73200
Detailed Description
Professional Grade Heating for Classic Restorations ال APCF-63-85017 is built to meet the rigorous demands of classic vehicle maintenance. Unlike standard aftermarket units, our mechanical heater core uses a precision expansion process to ensure the aluminum tubes and fins maintain perfect contact, even after years of vibration and thermal cycling.
Key Technical Features:
-
Enhanced Heat Exchange: The core is designed with internal turbulators that optimize coolant flow, ensuring your cabin warms up quickly even in extreme winter conditions.
-
First-Fit Reliability: As a direct technical equivalent to the نيسن 73200, this unit matches all original mounting points and pipe orientations.
-
Stress-Tested Performance: Every batch undergoes a series of life tests, including pressure impulse, thermal expansion, and corrosion testing to eliminate the risk of cabin leaks.
-
Superior Materials: We use premium-grade aluminum for the core and fiberglass-reinforced plastic (PA66-GF30) for the tanks to ensure a service life that exceeds original factory standards.
Product Technical Specifications
| ميزة | Specification |
| الشركة المصنعة | أجزاء السيارات الصين مصنع (APCF) |
| Exporter Part Number | APCF-63-85017 |
| Cross Reference | نيسن 73200 |
| OE Part Numbers | 7701007674, 7701014934, 7701026281 |
| Core Type | ميكانيكية (Mechanically Jointed) |
| Core Dimensions | 147 x 138 x 42 مم |
| Seal Material | EPDM (Ethylene Propylene Diene Monomer) |
Vehicle Compatibility
This radiator is a direct replacement for the following models:
-
Renault 4: (1962–1993) – All Saloon, Estate, and Fourgonnette (Van) النماذج.
-
Renault 5: (1972–1985) – Early generation R5 models.
-
Engines: 0.7L, 0.8L, 1.0L, 1.1L Petrol.
- Renault R4 0.7 Engine: 680 702 from 04/1962 ل 04/1971
Renault R4 0.8 Engine: 839 706 from 01/1981 ل 09/1982
Renault R4 0.8 (R1123) Engine: 800 705 from 10/1962 ل 09/1983
Renault R4 0.8 (R1123) Engines: 800 705, B1B 707 from 10/1983 ل 10/1988
Renault R4 1.0 (112C) Engine: C1C 708 from 06/1987 ل 06/1993
Renault R4 1.1 (1128, S128) Engines: 688 712, C1E 714, C1E 719 from 06/1978 ل 06/1990
Renault R4 Van 0.8 Engine: 839 706 from 09/1971 ل 08/1982
Renault R4 Van F4 0.8 (R2391) Engines: 800 705, B1B 707 from 04/1983 ل 07/1989
Renault R4 Van 0.8 (R2106) Engine: 800 01 from 09/1966 ل 12/1988
Renault R4 Van F6 1.1 (R2370, 210B) Engines: 688 711, 688 712, C1E 714, C1E 718, C1E 719 from 10/1976 ل 07/1989
Renault R4 Van F4 1.1 (239B) Engines: C1E 718, C1E 719 from 07/1982 ل 05/1989
Cross-Reference (OE Numbers)
-
RENAULT (OE): 7701007674, 7701014934, 7701026281
-
نيسن: 73200
-
جبهة الخلاص الوطني: 506603
-
VALEO: 883713
-
MAGNETI MARELLI: 350218197000
